Have you ever had this experience: rushing to take an important call with wireless earbuds, only to hear choppy audio filled with static; or trying to check your heart rate data on a smartwatch during a workout, but the screen suddenly goes black—these frustrating malfunctions often come down to a small yet critical component: the Flexible Printed Circuit (FPC).
In portable devices like earbuds, smartwatches, and foldable phones, internal space is extremely limited, and components must withstand frequent bending and vibration (such as the opening and closing of a foldable phone screen). FPCs act as the "nervous system" here, connecting batteries, screens, sensors, and chips. The quality of their assembly directly determines whether a device operates stably or malfunctions frequently. Below are 4 key steps to ensure FPC connection reliability:
Before assembly, even a single speck of dust or a trace of oil on FPC pads or device connectors can block current transmission. Manufacturers must use ultrasonic cleaners with specialized solvents to thoroughly remove contaminants—this step is non-negotiable. A certain brand of earbuds once saw 30% of its products develop call static issues due to inadequate cleaning.
FPCs are thin, lightweight, and flexible, making misalignment easy during manual assembly. The current mainstream practice uses automated equipment with high-magnification cameras to control the alignment error between FPC pins and connector slots to within 0.1mm. For example, if the FPC for a smartphone’s touchscreen is misaligned by just 0.2mm, it will cause touch failure.
Whether using heat-sealing welding or adhesive bonding, pressure and temperature must be strictly controlled: excessive pressure may break the copper wires inside the FPC, while insufficient pressure leads to loose connections; overly high temperatures damage the FPC substrate, and overly low temperatures fail to form a stable bond. For smartwatches, their FPCs typically require bonding at 120°C for 10 seconds—any deviation from these parameters will shorten the device’s lifespan.
Finally, two key tests are mandatory: Automated Optical Inspection (AOI) to check for welding defects, and electrical testing to verify stable signal transmission. Previously, a well-known smart band brand skipped some testing steps, leading to FPC connection failures in 50,000 units. In the end, the brand had to recall and rectify the products.
Today, we rely on portable devices for work, health monitoring, and even socializing—FPC assembly is no longer just a simple production step; it is the "invisible cornerstone" of device reliability. Every precise operation in these steps ensures that your earbuds stay clear and stable during calls, your smartwatch accurately records every workout session, and these portable devices truly become reliable helpers in your life.
