Rigid-flex PCBs are a game-changer for compact, durable devices—but when it comes to cost, misinformation runs rampant. Engineers and purchasing teams often hear claims like, “Rigid-flex is always 2x more expensive than rigid PCBs” or “Small batches aren’t worth it” — and these myths can derail projects before they start. The truth is, rigid-flex costs depend on design choices, volume, and supplier partnerships—not just the technology itself. Let’s debunk the top cost myths with real-world examples, so you can make informed decisions for your project.
The Rumor: Many believe combining rigid and flexible layers automatically makes rigid-flex pricier than using separate rigid PCBs connected by wires or connectors (called “PCBAs”).
The Reality: Rigid-flex eliminates the need for connectors, wires, and manual assembly—saving money in the long run.
Take a U.S. IoT sensor maker’s experience:
-
They initially planned to use two rigid PCBs (for the sensor and battery) connected by 3 wires and 2 connectors. The cost breakdown: $2.50 per rigid PCB (x2 = $5), $0.80 for connectors, $0.30 for wires, and $1.20 for manual assembly—**total $7.30 per unit**.
-
When they switched to a rigid-flex design, the PCB cost rose to $6 per unit—but they cut out connectors, wires, and assembly. The new total? **$6 per unit**—a 18% savings.
Why? Rigid-flex reduces “hidden costs”: connectors are failure points (leading to $$$ recalls), and manual assembly slows production. For devices that need reliability (like medical wearables), the savings from fewer defects alone can offset higher PCB costs.
The Rumor: Suppliers only offer rigid-flex at a reasonable price for large volumes (1000+ units); small batches are prohibitively expensive.
The Reality: Modern manufacturing has made small-batch rigid-flex affordable—if you choose the right supplier and design.
A European startup building a prototype for a foldable medical monitor faced this myth:
-
They were quoted $150 per rigid-flex PCB for 50 units by their first supplier—way over budget.
-
They switched to a supplier specializing in low-volume prototypes, which used “panelization” (fitting multiple small PCBs on one production panel) and standard materials (e.g., 1oz copper, polyimide substrate). The new quote? $45 per unit—a 70% drop.
Key fix: Avoid over-engineering small batches. Skip custom materials (like high-temperature polyimide) or complex features (e.g., microvias under 0.1mm) unless absolutely necessary. Most prototypes don’t need industrial-grade specs—standard rigid-flex works just fine.
The Rumor: Every extra flexible layer (e.g., 2-layer vs. 4-layer flex) drives up costs exponentially.
The Reality: Flexible layer costs rise linearly—not exponentially—and often don’t need as many layers as you think.
A Chinese consumer electronics firm designing a smartwatch learned this:
-
They initially designed a 4-layer flexible section to fit all components, expecting it to cost 2x more than a 2-layer.
-
Their supplier reviewed the design and found 2 layers were enough: they rearranged components to use the rigid section for most traces, leaving only essential connections for the flexible layer. The 2-layer flex cost only 30% more than a 1-layer—far less than the 100% increase they feared.
Rule of thumb: Use flexible layers only for parts that need to bend. Keep as many components and traces as possible on the rigid section—rigid layers are cheaper and easier to manufacture.
The Rumor: You need specialized, costly software to design rigid-flex PCBs—far beyond standard PCB tools like Altium or KiCad.
The Reality: Most modern PCB design tools have built-in rigid-flex features—no extra cost required.
A Canadian engineer building a drone’s camera module proved this:
-
He used Altium Designer (his existing tool) to design a rigid-flex PCB for the drone. He only needed to: 1) Mark rigid and flexible regions in the software, 2) Set bend radii (e.g., 1mm for the flex section), and 3) Check for trace alignment across layers.
-
No extra software, no extra fees—he finished the design in 2 weeks, same as a rigid PCB.
Suppliers also offer free design checks: Send your rigid-flex layout to a supplier, and they’ll flag issues (e.g., traces too close to the flex-rigid junction) for free. This avoids costly redesigns later.
The Rumor: Rigid-flex takes 4–6 weeks to manufacture—slower than rigid PCBs (1–2 weeks)—and delays cost money (e.g., missed product launches).
The Reality: Regional suppliers and “quick-turn” services cut lead times to 7–10 days for standard rigid-flex designs.
A U.S. automotive parts maker needed 200 rigid-flex PCBs for a prototype deadline:
-
They first contacted an overseas supplier, which quoted 4 weeks. Fearing a missed deadline (and a $10k penalty), they switched to a U.S.-based supplier with quick-turn services.
-
The U.S. supplier delivered the 200 PCBs in 9 days—for only a 15% premium over standard lead times. The maker avoided the penalty and launched on time.
Pro tip: Plan for 1–2 extra days of design checks (to avoid errors), but don’t assume rigid-flex is always slow. Regional suppliers often have shorter shipping times too—no customs delays.
-
Collaborate with Suppliers Early: Share your design goals (e.g., “needs to bend 10k times”) with a rigid-flex supplier before finalizing the layout. They’ll suggest cost-saving tweaks (e.g., using a thinner flex layer) you might miss.
-
Calculate Total Cost of Ownership (TCO): Don’t just look at PCB cost—include assembly, defects, and maintenance. Rigid-flex often has lower TCO because it has fewer parts to fail.
-
Test with Small Batches First: Order 50–100 units to validate the design and cost. If it works, scale up—this avoids wasting money on large batches of a flawed design.
Rigid-flex PCBs aren’t inherently expensive—misinformation makes them seem that way. By debunking these myths, you’ll see that rigid-flex can save money (by cutting connectors and assembly), work for small batches, and use tools you already have. The key is to focus on smart design (e.g., minimal flex layers) and strong supplier partnerships (e.g., regional quick-turn services). For projects that need compactness, durability, or flexibility, rigid-flex isn’t a “costly upgrade”—it’s a cost-effective solution.
