Short Description:

Product Type: 2 layer Flex-Rigid PCB
Applications: automotive radar,car radar,vehicle radar
Material: PI,Copper,adhesive,FR4,PP
Line width and line spacing：0.2mm/0.2mm
Board thickness：1.0mm +/- 10%
Minimum hole:0.2mm
Surface Treatment:ENIG 2-3uin

Impedance:/

Tolerance tolerance:±0.1MM

Capel’s Service:

Support Custom 1-30 Layer FPC Flexible PCB,2-32 Layer Rigid-Flex Circuit Boards,1-60 Layer Rigid PCB,HDI PCB,Reliable Quick Turn PCB Prototyping,Fast Turn SMT PCB Assembly

Industry We Service:

Medical Device, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…

High-Quality 2 Layer Automotive Radar PCBs - Boost Your Automotive Systems
-Capel with 15 years of professional technical experience-

Introducing our high-quality 2-layer rigid-flex PCB designed specifically for automotive radar, automotive radar, and automotive radar applications. Our PCBs are manufactured using top quality materials including PI, Copper, Adhesives, FR4 and PP to ensure durability and reliability in the most demanding automotive environments.

Our PCB line width and line spacing are 0.2mm/0.2mm, and the board thickness is 1.0mm +/- 10%, which can meet the strict requirements of automotive radar systems. The minimum hole diameter of 0.2mm allows for precision and accurate assembly, while the ENIG 2-3uin surface treatment ensures excellent conductivity and corrosion resistance.

We understand the importance of precision and accuracy in automotive radar systems, which is why our PCBs are manufactured to a tolerance of ±0.1MM to ensure consistent and reliable performance. Our PCB impedance is optimized for automotive radar applications, further improving radar system performance and reliability.

Our 2-layer rigid-flex PCBs are rigorously tested to meet the highest industry standards and have been proven to deliver superior performance in automotive radar applications. Whether it's collision avoidance, adaptive cruise control or parking assistance, our PCBs are designed to meet the ever-changing needs of automotive radar systems.

By choosing our high-quality 2-layer rigid-flex PCBs, you can improve the performance of your automotive radar system and ensure a safer, more reliable driving experience. Our PCBs are trusted by leading automotive manufacturers and suppliers and have a proven track record of delivering superior performance in the most demanding automotive environments.

In addition to automotive radar applications, our PCBs are suitable for a variety of other applications, making them a versatile and cost-effective solution to your electronic design needs. Whether it's consumer electronics, industrial equipment or telecommunications systems, our PCBs meet the most demanding requirements.

At Shenzhen Capel Technology Co., Ltd., we are committed to providing our customers with high-quality, reliable PCB solutions. With our expertise in PCB manufacturing and design, we are able to provide customized solutions to meet our customers' unique requirements. Our team of experts is dedicated to ensuring the highest level of quality and reliability in every PCB we produce.

Choose our high-quality 2-layer rigid-flex PCBs for your automotive radar applications and experience the difference in performance and reliability. With our proven track record of delivering exceptional quality and performance, you can trust us to meet your PCB needs and exceed your expectations. Contact us today to learn more about our PCB solutions and how we can help you achieve your electronic design goals.
