Short Description:

Product Type: 2 layer Flex PCB
Applications: Car
Material: PI,Copper,adhesive
Line width and line spacing：0.15mm/0.2mm
Board thickness：0.23mm +/- 0.03mm
Minimum hole:0.1mm
Surface Treatment:ENIG 2-3uin

Impedance:/

Tolerance tolerance:±0.1MM

Capel’s Service:

Support Custom 1-30 Layer FPC Flexible PCB,2-32 Layer Rigid-Flex Circuit Boards,1-60 Layer Rigid PCB,HDI PCB,Reliable Quick Turn PCB Prototyping,Fast Turn SMT PCB Assembly

Industry We Service:

Medical Device, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…

Our multi-layer automotive flexible PCB boards provide automotive manufacturers with reliable prototyping solutions
-Capel with 15 years of professional technical experience-

Introducing our state-of-the-art 2-layer flexible PCB, designed for automotive applications. Our multi-layer automotive flexible PCB boards provide automotive manufacturers with reliable prototyping solutions, ensuring high-quality performance and durability.

Our flexible PCBs are made from advanced materials such as PI, copper and adhesives to withstand the harsh conditions of the automotive environment. Our PCB board thickness is 0.23mm +/- 0.03mm, providing a strong and safe foundation for automotive electrical systems.

Our flexible PCBs have fine-tuned line widths and line spacings of 0.15mm/0.2mm, enabling precise and efficient electrical connections within vehicles. In addition, our PCBs have apertures as small as 0.1mm, which can accommodate complex circuits and are ideal for the advanced technology found in modern cars.

To ensure optimal functionality and longevity, our flexible PCBs are ENIG (Electroless Nickel Immersion Gold) treated and are 2-3uin thick, providing excellent corrosion resistance and solderability for automotive environments.

Our flexible PCBs are designed to provide consistent and reliable performance, meeting the rigorous standards of the automotive industry. With a tolerance of ±0.1mm, our PCBs provide precise manufacturing to meet the exacting requirements of automotive manufacturers.

Whether used in vehicle infotainment systems, engine control units, sensors or other critical automotive components, our 2-layer flexible PCBs are ideal for a variety of applications in the automotive field.

We understand the importance of innovation and reliability in the automotive industry, which is why our flexible PCBs are designed to meet the ever-changing needs of automotive manufacturers. Using our comprehensive understanding of automotive electrical systems, we develop a product with the highest levels of performance, durability and safety.

In summary, our 2-layer flexible PCBs are the perfect solution for automotive applications, providing unparalleled reliability and performance. With precision construction, high-quality materials and advanced surface treatments, our PCBs meet the stringent requirements of the automotive industry. Upgrade your automotive electrical system with our advanced flexible PCBs and experience the difference in quality and reliability.
