Short Description:

Product Type: 2 layer Flex PCB
Applications: Car
Material: PI,Copper,adhesive，FR4
Line width and line spacing：0.15mm/0.2mm
Board thickness：0.23mm +/- 0.03mm
Minimum hole:0.1mm
Surface Treatment:ENIG 2-3uin

Impedance:/

Tolerance tolerance:±0.1MM

Capel’s Service:

Support Custom 1-30 Layer FPC Flexible PCB,2-32 Layer Rigid-Flex Circuit Boards,1-60 Layer Rigid PCB,HDI PCB,Reliable Quick Turn PCB Prototyping,Fast Turn SMT PCB Assembly

Industry We Service:

Medical Device, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…

The Benefits of 2 Layer Printed Circuit Boards for Electric Vehicle Flex PCB Fabrication
-Capel with 15 years of professional technical experience-

Introducing our latest product - a 2-layer flexible PCB designed specifically for electric vehicles. As the demand for electric vehicles continues to grow, so does the need for high-quality and reliable circuit boards. Our 2-layer flexible PCBs are the perfect solution for the growing electric vehicle market.

Our 2-layer flex PCBs are constructed from durable and reliable materials such as PI, Copper, Adhesives and FR4, ensuring the highest level of performance and longevity. The use of these materials also allows for board thicknesses of 0.23 mm with tolerances of +/- 0.03 mm, ideal for compact designs in electric vehicles.

One of the key features of our 2-layer flex PCBs is their impressive 0.15mm/0.2mm line width and spacing, as well as a minimum hole size of 0.1mm. This precision and accuracy ensures the board can effectively handle the complex, high-performance systems found in electric vehicles.

Additionally, our 2-layer flexible PCBs feature an ENIG 2-3uin surface treatment, further enhancing their durability and resistance to environmental factors. This makes it ideal for use in the demanding conditions of the automotive industry.

The applications of our 2-layer flexible PCBs are not limited to electric vehicles but can also be used in various other automotive applications. Its versatility and reliability make it an ideal choice for any automotive electronic system.

One of the most important aspects of our 2-layer flex PCB is its ability to meet the specific requirements of electric vehicles, including impedance and tolerances. With our 2-layer flex PCB, you can be sure it will meet the automotive industry's stringent standards.

Overall, the advantages of our 2-layer flexible PCB for electric vehicles are obvious. Its high-quality materials, precision manufacturing and reliability make it the perfect choice for any electric vehicle application. If you want to ensure the high

Capel Flexible PCB & Rigid-Flex PCB Process Capability

Category	Process Capability	Category	Process Capability
Production Type	Single layer FPC / Double layers FPC Multi-layer FPC / Aluminum PCBs Rigid-Flex PCB	Layers Number	1-30 layers FPC 2-32 layers Rigid-FlexPCB 1-60 layers Rigid PCB HDI Boards
Max Manufacture Size	Single layer FPC 4000mm Double layers FPC 1200mm Multi-layers FPC 750mm Rigid-Flex PCB 750mm	Insulating Layer Thickness	27.5um /37.5/ 50um /65/ 75um / 100um / 125um / 150um
Board Thickness	FPC 0.06mm - 0.4mm Rigid-Flex PCB 0.25 - 6.0mm	Tolerance of PTH Size	±0.075mm
Surface Finish	Immersion Gold/Immersion Silver/Gold Plating/Tin Plating/OSP	Stiffener	FR4 / PI / PET / SUS / PSA/Alu
Semicircle Orifice Size	Min 0.4mm	Min Line Space/ width	0.045mm/0.045mm
Thickness Tolerance	±0.03mm	Impedance	50Ω-120Ω
Copper Foil Thickness	9um/12um / 18um / 35um / 70um/100um	Impedance Controlled Tolerance	±10%
Tolerance of NPTH Size	±0.05mm	The Min Flush Width	0.80mm
Min Via Hole	0.1mm	Implement Standard	GB / IPC-650 / IPC-6012 / IPC-6013II / IPC-6013III

Capel manufactures customized high-precision Rigid Flexible Circuit Board / Flexible PCB / HDI PCB with 15 years of experience with our professionalism

2 Layer Flexible PCB Boards Stackup

4 Layer Rigid-Flex PCB Stackup

8 layer HDI PCBs

Testing And Inspection Equipment

Microscope Testing

AOI Inspection

2D Testing

Impedance Testing

RoHS Testing

Flying Probe

Horizontal Tester

Bending Teste

Capel provide customers customized PCB Service with 15 years of experience

Owning 3 factories for Flexible PCB&Rigid-Flex PCB, Rigid PCB, DIP/SMT Assembly;
300+Engineers Provide technical support for Pre-sales and after-sales online;
1-30 layers FPC, 2-32 layers Rigid-FlexPCB, 1-60 layers Rigid PCB
HDI Boards, Flexible PCB (FPC), Rigid-Flex PCBs, Multilayer PCBs, Single-sided PCB, Double-Sided Circuit Boards, Hollow Boards, Rogers PCB, rf PCB, Metal Core PCB, Special Process Boards, Ceramic PCB, Aluminum PCB, SMT & PTH Assembly, PCB Prototype Service.
Provide 24-hour PCB Prototyping service,Small Batches of circuit boards will be delivered in 5-7 days, Mass Production of PCB boards will be delivered in 2-3 weeks;
Industries we service: Medical Devices, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…
Our Production Capacity:
FPC and Rigid-Flex PCBs production capacity can reach more than 150000sqm per month,
PCB production capacity can reach 80000sqm per month,
PCB Assembling capacity at 150,000,000 components per month.
Our teams of engineers and researchers are dedicated to fulfilling your requirements with precision and professionalism.
