Kaboer’s Single-Sided Flexible PCB for Automotive Navigation is tailor-made for core navigation components such as in-vehicle navigation host signal adapters, navigation display module interfaces, GPS positioning signal transmission units, and navigation key control boards. It precisely addresses the core demands of automotive navigation scenarios—stable signal transmission, automotive environment resistance, compact adaptation, and cost-effectiveness—with a highly adaptive configuration of "1mil immersion gold finish + practical single-sided wiring". As a reliable and cost-competitive preferred solution in the automotive navigation electronics field, it empowers automakers and supporting manufacturers to develop in-vehicle navigation systems with smooth signals and strong durability!
Featuring a single-sided flexible core structure, it perfectly balances the space adaptability and operational reliability of navigation devices: with an overall thickness of only 0.13mm, it is extremely slim and boasts excellent bending resilience, seamlessly fitting narrow internal cavities, curved mounting positions, and component joints of navigation hosts (e.g., between navigation screens and motherboards, GPS modules and control units). It easily avoids wiring interference, adapting to the modular and compact design needs of in-vehicle navigation, and completely solving the pain point of poor adaptability of traditional rigid PCBs in complex layouts of navigation devices; with precise dimensions of 68.2*115mm, the optimized slim layout supports integration of core navigation components (e.g., simultaneous layout of signal interfaces, key contacts, and small driver chips) without occupying redundant space, leaving ample installation room for other functional modules inside navigation devices; the 0.3/0.8mm wide line width/spacing balances signal transmission stability and current-carrying capacity, adapting to basic transmission needs of GPS positioning signals, display data, and control commands in navigation devices, ensuring consistent circuit conduction and signal integrity.
Key advantages directly tackle pain points in automotive navigation scenarios, demonstrating automotive-grade practical performance: ① Equipped with 1mil immersion gold finish, it offers excellent oxidation resistance, wear resistance, and low contact resistance. It can withstand the wide temperature range of -40℃ to 85℃ in vehicles (low-temperature startup in winter, high temperature from summer exposure) as well as complex working conditions such as high humidity and dust, avoiding issues like GPS signal loss, navigation lag, and key failure caused by oxidation or poor contact. Meanwhile, the immersion gold surface enhances terminal plug-in durability and soldering reliability, adapting to the long-term high-frequency use of automotive navigation; ② The single-sided wiring design balances cost-effectiveness and maintenance convenience, meeting the non-core signal transmission needs of navigation devices while effectively controlling procurement and production costs. With clear wiring logic, it enables more efficient later fault diagnosis, adapting to the mass production and after-sales maintenance rhythm of automotive electronics; ③ The flexible substrate features excellent vibration resistance and fatigue resistance, withstanding bumps, vibrations, road impacts during vehicle driving, and slight bending during long-term use. It reduces circuit failures caused by automotive environmental factors, aligning with the core demand of "long service life and low failure rate" for automotive electronics.
Backed by Kaboer’s years of technical expertise in flexible PCBs and strict quality control systems, this single-sided flexible PCB for automotive navigation can be customized for circuit layout, contour, and mounting holes based on the functional needs of navigation devices (e.g., interface type, signal transmission protocol, installation method). Paired with full-chain services including "1-30 layer FPC customization, rapid prototyping, and efficient SMT assembly", it helps customers shorten R&D cycles and accelerate product mass production. Whether for stable GPS signal transmission of in-vehicle navigation, data connection of display modules, or precise command transmission of key controls, it serves as a "reliable signal link" for automotive navigation devices with core advantages of "high adaptability, high durability, and high cost-effectiveness", helping enterprises reduce costs, enhance product competitiveness, and gain an edge in the automotive navigation electronics niche market!
