4 layer FPC Flexible PCB Boards FR4 ENIG Circuit Boards for PlayStation Gaming Device

Short Description:

Product type：4 layer FPC Flexible PCB Boards
Applications:PlayStation Gaming Device
Line width and line spacing：0.075mm/0.075mm
Board thickness：0.13mm
Minimum Aperture:0.15mm
Copper Thickness:35um
Surface Treatment:Immersion Gold
Special Process:/
stiffness:FR4

Capel’s Service:
Support Custom 1-30 Layer FPC Flexible PCB,2-32 Layer Rigid-Flex Circuit Boards,1-60 Layer Rigid PCB,Reliable Quick Turn PCB Prototyping,Fast Turn SMT PCB Assembly

Industry We Service:
Medical Device, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…

How Capel's 4 Layer FPC Flexible PCB Boards FR4 ENIG Circuit Boards Provides Reliability Solutions for PlayStation Gaming Device manufacturers
-Capel with 15 years of professional technical experience-

Launched a breakthrough 4-layer FPC flexible PCB board designed specifically for the popular PlayStation gaming device. This innovative product combines advanced technology and expert engineering to deliver unparalleled performance and reliability.

These boards are precision manufactured with an impressive line width and line spacing of 0.075mm/0.075mm, ensuring seamless connectivity and superior signal transmission. Additionally, the ultra-thin board thickness of 0.13 mm provides flexibility, making it easier to integrate into any gaming device.

One of the main features of these 4-layer FPC flexible PCB boards is their minimum aperture size of 0.15 mm. This ensures accurate alignment and precise installation of components, helping to improve the overall efficiency and effectiveness of your gaming equipment.

The copper thickness of these PCB boards is 35um, providing excellent electrical conductivity for reliable, continuous electrical connections. This property is crucial to maintain smooth gaming and enhanced user experience.

To further enhance the quality and durability of these PCB boards, they are immersed in gold. This surface treatment not only provides a protective layer against corrosion and wear, but also provides superior conductivity for long-lasting performance.

The 4-layer FPC flexible PCB board is manufactured using a special process to ensure its reliability and ability to withstand rigorous gaming operations. This special process ensures that the circuit board can withstand various challenges such as temperature fluctuations, mechanical stress and environmental factors.

Additionally, the stiffness of these PCB boards is enhanced with FR4 material, allowing them to withstand harsh gaming conditions. This feature ensures that the motherboard will last without compromising its performance and functionality.

The applications of these 4-layer FPC flexible PCB boards are wide and diverse. Designed specifically for PlayStation gaming devices, these motherboards enhance the gaming experience by enabling seamless connectivity, improved signal transmission and uninterrupted gameplay. These motherboards meet the demands of high-performance gaming, ensuring gamers can fully immerse themselves in the gaming world.

Not only are these boards ideal for gaming applications, but they can also be used in other areas where flexibility and compactness are required, such as portable devices, medical equipment, aerospace technology, and more. Their versatility makes them an excellent choice for numerous industries.

In conclusion, 4-layer FPC flexible PCB board is a game changer in the field of gaming equipment. With their advanced technology, precision engineering and superior performance, these motherboards will revolutionize the gaming experience. Designed specifically for PlayStation gaming devices, these motherboards provide gamers with the reliability, flexibility and functionality they need to fully immerse themselves in the world of gaming. Don't settle for less; choose a 4-layer FPC flexible PCB board for the ultimate gaming experience.

Capel Flexible PCB & Rigid-Flex PCB Process Capability

Category	Process Capability	Category	Process Capability
Production Type	Single layer FPC / Double layers FPC Multi-layer FPC / Aluminum PCBs Rigid-Flex PCB	Layers Number	1-30 layers FPC 2-32 layers Rigid-FlexPCB 1-60 layers Rigid PCB HDI Boards
Max Manufacture Size	Single layer FPC 4000mm Double layers FPC 1200mm Multi-layers FPC 750mm Rigid-Flex PCB 750mm	Insulating Layer Thickness	27.5um /37.5/ 50um /65/ 75um / 100um / 125um / 150um
Board Thickness	FPC 0.06mm - 0.4mm Rigid-Flex PCB 0.25 - 6.0mm	Tolerance of PTH Size	±0.075mm
Surface Finish	Immersion Gold/Immersion Silver/Gold Plating/Tin Plating/OSP	Stiffener	FR4 / PI / PET / SUS / PSA/Alu
Semicircle Orifice Size	Min 0.4mm	Min Line Space/ width	0.045mm/0.045mm
Thickness Tolerance	±0.03mm	Impedance	50Ω-120Ω
Copper Foil Thickness	9um/12um / 18um / 35um / 70um/100um	Impedance Controlled Tolerance	±10%
Tolerance of NPTH Size	±0.05mm	The Min Flush Width	0.80mm
Min Via Hole	0.1mm	Implement Standard	GB / IPC-650 / IPC-6012 / IPC-6013II / IPC-6013III

Capel manufactures customized high-precision Rigid Flexible Circuit Board / Flexible PCB / HDI PCB with 15 years of experience with our professionalism
