4 layer Rigid-Flex PCB Boards Price Turnkey Manufacturing And Assembly Fab for Aerospace-Pcb Manufacturer, Rigid Flex Pcb, Flexible Pcb

4 layer Rigid-Flex PCB Boards Price Turnkey Manufacturing And Assembly Fab for Aerospace

Short Description:

Product Type:4 layer Rigid Flexible PCB Boards
Applications: Aerospace
Line width and line spacing：0.15mm/0.15mm
Board thickness：1.6mm+-10%
Layers Stackup:1+2+1
Minimum Aperture:0.2mm
Copper Hole Thickness:35UM
Surface Treatment:ENIG 2-3uin

Impedance:/
Warpage:≦0.5%

Tolerance Accuracy:±0.1MM

Capel’s Service:

Support Custom 1-30 Layer FPC Flexible PCB,2-32 Layer Rigid-Flex Circuit Boards,1-60 Layer Rigid PCB,HDI PCB,Reliable Quick Turn PCB Prototyping,Fast Turn SMT PCB Assembly

Industry We Service:

Medical Device, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…

How Capel's 4 Layer Rigid-Flex PCB Boards Provides Reliability Solutions for Aerospace manufacturers
-Capel with 15 years of professional technical experience-

Introducing our state-of-the-art 4-layer rigid-flex PCB board designed and manufactured specifically for aerospace applications. These high-performance PCB boards are built to withstand the rigors of the aerospace industry, ensuring durability and reliability in even the most demanding environments.

Our 4-layer rigid-flex PCB boards feature 0.15mm/0.15mm line width and line spacing, providing superior precision and accuracy. The plate thickness of 1.6mm+-10% provides a solid foundation for optimal performance. The 1+2+1 layer stacking enables efficient space utilization and simplified connections.

Our PCB boards have a minimum hole diameter of 0.2mm, providing excellent signal integrity and ensuring smooth and efficient operation. The 35UM copper hole thickness further enhances the stability and conductivity of the board. To provide enhanced protection and longer life, our 4-layer rigid-flex PCB boards feature an ENIG 2-3uin surface treatment, making them corrosion and abrasion resistant.

In terms of performance, our 4-layer rigid-flex PCB boards have an impressive warpage tolerance of ≤0.5%, ensuring optimal functionality even under extreme conditions. Tolerance accuracy of ±0.1mm ensures precise and consistent performance, meeting the highest standards of quality and reliability.

As a turnkey manufacturer, we offer comprehensive services including PCB board fabrication and assembly manufacturing, making it easy for aerospace companies to source their PCB needs from a single, reliable supplier. Our efficient manufacturing processes ensure competitive pricing without compromising on quality.

With our 4-layer rigid-flex PCB boards, aerospace companies can benefit from superior performance, outstanding durability and seamless connections. Trust us to meet all your aerospace PCB requirements and experience the difference in quality and performance. Contact us today to learn more about 4-layer rigid-flex PCB boards and discuss your specific application needs.

Capel Flexible PCB & Rigid-Flex PCB Process Capability

Category	Process Capability	Category	Process Capability
Production Type	Single layer FPC / Double layers FPC Multi-layer FPC / Aluminum PCBs Rigid-Flex PCB	Layers Number	1-30 layers FPC 2-32 layers Rigid-FlexPCB 1-60 layers Rigid PCB HDI Boards
Max Manufacture Size	Single layer FPC 4000mm Double layers FPC 1200mm Multi-layers FPC 750mm Rigid-Flex PCB 750mm	Insulating Layer Thickness	27.5um /37.5/ 50um /65/ 75um / 100um / 125um / 150um
Board Thickness	FPC 0.06mm - 0.4mm Rigid-Flex PCB 0.25 - 6.0mm	Tolerance of PTH Size	±0.075mm
Surface Finish	Immersion Gold/Immersion Silver/Gold Plating/Tin Plating/OSP	Stiffener	FR4 / PI / PET / SUS / PSA/Alu
Semicircle Orifice Size	Min 0.4mm	Min Line Space/ width	0.045mm/0.045mm
Thickness Tolerance	±0.03mm	Impedance	50Ω-120Ω
Copper Foil Thickness	9um/12um / 18um / 35um / 70um/100um	Impedance Controlled Tolerance	±10%
Tolerance of NPTH Size	±0.05mm	The Min Flush Width	0.80mm
Min Via Hole	0.1mm	Implement Standard	GB / IPC-650 / IPC-6012 / IPC-6013II / IPC-6013III

Capel manufactures customized high-precision Rigid Flexible Circuit Board / Flexible PCB / HDI PCB with 15 years of experience with our professionalism

2 Layer Flexible PCB Boards Stackup

4 Layer Rigid-Flex PCB Stackup

8 layer HDI PCBs

Testing And Inspection Equipment

Microscope Testing

AOI Inspection

2D Testing

Impedance Testing

RoHS Testing

Flying Probe

Horizontal Tester

Bending Teste

Capel provide customers customized PCB Service with 15 years of experience

Owning 3 factories for Flexible PCB&Rigid-Flex PCB, Rigid PCB, DIP/SMT Assembly;
300+Engineers Provide technical support for Pre-sales and after-sales online;
1-30 layers FPC, 2-32 layers Rigid-FlexPCB, 1-60 layers Rigid PCB
HDI Boards, Flexible PCB (FPC), Rigid-Flex PCBs, Multilayer PCBs, Single-sided PCB, Double-Sided Circuit Boards, Hollow Boards, Rogers PCB, rf PCB, Metal Core PCB, Special Process Boards, Ceramic PCB, Aluminum PCB, SMT & PTH Assembly, PCB Prototype Service.
Provide 24-hour PCB Prototyping service,Small Batches of circuit boards will be delivered in 5-7 days, Mass Production of PCB boards will be delivered in 2-3 weeks;
Industries we service: Medical Devices, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…
Our Production Capacity:
FPC and Rigid-Flex PCBs production capacity can reach more than 150000sqm per month,
PCB production capacity can reach 80000sqm per month,
PCB Assembling capacity at 150,000,000 components per month.
Our teams of engineers and researchers are dedicated to fulfilling your requirements with precision and professionalism.
