Caboer’s 3-Layer Rigid-Flex PCB for Medical Devices is tailor-made for core medical components such as minimally invasive instruments, portable diagnostic devices, ultrasound probes, and vital signs monitors. It precisely meets the core demands of medical scenarios—high reliability, sterile compatibility, accurate signaling, and narrow space adaptation—setting the standard for medical-grade performance as a trusted choice for medical device R&D, empowering enterprises to deliver safe, precise, and efficient healthcare solutions!
Adopting a 3-layer rigid-flex synergy structure, it perfectly balances adaptability and safety in medical equipment: the 0.11mm ultra-thin flexible layer offers exceptional bending toughness and fatigue resistance, flexibly fitting narrow cavities, curved structures, and moving joints inside medical devices. It easily avoids wiring interference, adapting to the bending operations of minimally invasive instruments and the compact layout of portable devices; the 1.58mm sturdy rigid layer meets the load-bearing standards of medical equipment, reliably supporting core components such as sensors, signal processing chips, and high-precision connectors. This achieves efficient integration of "flexible adaptation to complex device structures + rigid fixation of precision parts". With precise dimensions of 40.5*62mm, the compact layout saves valuable space, providing ample room for the miniaturization and lightweight design of medical devices.
Key advantages directly address medical scenario pain points, demonstrating medical-grade robustness: ① Full-board immersion gold finish delivers superior resistance to sterilization wipes (compatible with medical disinfectants such as alcohol and hydrogen peroxide), oxidation, and corrosion. Low contact resistance ensures high-speed, distortion-free transmission of physiological signals (e.g., heart rate, blood pressure, ultrasound images), meeting the long-term high-frequency use and sterile maintenance requirements of medical devices; ② White text solder mask + through-hole design features clear markings, facilitating sterile module assembly, rapid debugging, and post-maintenance. It adapts to the high-cleanliness production standards of the medical manufacturing industry, improving mass production efficiency and operational safety; ③ 3-layer scientific wiring layout rationally separates signal, power, and ground layers, effectively suppressing electromagnetic interference (EMI). Even in complex medical electromagnetic environments, it ensures seamless collaboration across the full process of "data collection - signal processing - result output", guaranteeing the reliability of diagnostic and therapeutic data and meeting the functional safety requirements of medical devices.
Backed by Caboer’s years of medical-grade PCB R&D experience and strict quality control system, this 3-layer rigid-flex PCB strictly complies with ISO 10993 biocompatibility standards and is compatible with global medical regulatory requirements (NMPA, FDA, CE). It can be customized for interface types, protection levels, and wiring routes based on specific medical device needs. Paired with rapid prototyping and efficient SMT assembly services, it helps customers shorten R&D cycles and accelerate product launch and certification processes. Whether for minimally invasive treatment instruments, in vitro diagnostic devices, or life support systems, it serves as the "core neural hub" of medical equipment with stable performance—helping enterprises reduce compliance risks and enhance product credibility and market competitiveness!
